DRONEs & STM32


Home Page







Link



-
LINK

  • OpenPilot
    • Based on STM32
    • OpenPilot is an all  next-generation Open Source UAV autopilot created by the OpenPilot Community (an all volunteer non-profit community).
    • It is a highly capable platform for multi-rotor craft, helicopters, as well as fixed wing aircraft. It has been designed from the ground up by a community of passionate developers from around the globe, with its core design principles being quality, safety, and ease of use.
    • Simplicity does not come with any compromises either: with no hard-coded settings, a complete flight plan scripting language and other powerful features, OpenPilot is an extremely capable UAV autopilot platform.

  • Smart AutoPilot
    • Based on STM32
    • Along with ordinary functions such as stabilization, altitude hold, GPS position hold, and waypoint flight modes it’s also planned to add a special simplified manual control mode.
    • Implementation of adaptive control algorithms is also planned.
    • Moreover, some interesting features, which no one of existing autopilots has today, are being implemented in SmartAP.

  • Flymaple Open-Drobe
    • The Flymaple is our Quadcopter controller, based on Maple Project. It uses an STM32F103RET6 (ARM Cortex-M3) as the main MCU.
    • Flymaple V1.1(SKU:DFR0188)

  • Autopilots Flymaple
    • Flymaple is a Quadcopter controller board, based on the Maple Project.
    • The FlyMaple embeds a STM32F103RET6 (ARM Cortex-M3) as it's main MCU. It integrates a 3-Axis accelerometer,a 3-Axis gyroscope,a 3-Axis compass and a barometric pressure sensor.
    • By using the 10 dgrees of freedom IMUs and powerful 72MHz high-performation microcontroller, flymaple is powerful enough to handle a complex algorithm and manage a robot motion system at the same time.

  • The Paparazzi Project
    • Paparazzi UAV (Unmanned Aerial Vehicle) is an open-source drone hardware and software project encompassing autopilot systems for multicopters/multirotors, fixedwing, helicopters and hybrid aircraft. Paparazzi, being open, enables users to add more features and improve the system. Using and improving Paparazzi is encouraged by the community.
    • Paparazzi is based on STM32.

  • The Crazyflie Nano Quadcopter - based on STM32
    • The Crazyflie Nano Quadcopter is a miniature quadcopter that fits in your hand.
    • It only weights about 19 grams and is 9 cm motor-to-motor.
    • Aside from being fun to fly, it’s main purpose is to be a versatile development platform that can be used to experiment, develop and explore a lot of different areas of technology.
    • For input a wide range of controllers can be used when connected to your PC. There are also RC-controllers that you can connect directly to the Crazyflie Nano Quadcopter. For more information on controllers have a look at the controller page.

  • Smallest drone autopilost system
    • The Lisa/S chip is 4 square-centimeters (based on STM32) — about the same size as a Euro coin. But this 1.9-gram sliver of silicon includes everything you need to autopilot an aerial drone.
      It’s the world’s smallest drone autopilot system — over 30 grams lighter than its predecessor — according to the chip’s designers at the Delft University of Technology in the Netherlands. And best of all, both the hardware and the software is open source, meaning anyone can copy and use it — for free.
    • The Lisa/S is the MAV Laboratory’s latest project.
      The chip’s software is based on Paparazzi, an open source drone autopilot system that’s been around since 2003. The real innovation is the hardware.
      The tiny chip packs in everything you need for an autopilot system, including a gyroscope, accelerometer, altimeter, GPS, and an ARM processor.

      The Lisa/S can be used with any type of drone, from quadcopters to fixed-wing systems, Remes says.
    • See also the 1Bitsquared.
