July 2016 Ultra-low-power STM32L4, rationalized peripheral set ensures cost-optimized solutions from STMicroelectronics

Offering a rationalized peripheral set, our two new ultra-low-power STM32L4 product lines provide a cost-optimized solution.

With up to 256 Kbytes of Flash memory, our new STM32L43x MCUs comprise variants with versatile combinations of an integrated USB controller and LCD controller, while STM32L44x MCUs also include an AES encryption hardware accelerator for security-conscious applications.

Developers will appreciate the new slim-form-factor NUCLEO-L432KC board – the first Nucleo-32 board integrating the new QFN32 package - and get direct access to ARM® mbed™ online tools.

Design guides:
  • Overview of the STM32L4’s ultra-low-power features (AN4621)
  • How to optimize power and performance with STM32L4 microcontrollers (AN4746)
  • A complete set of training modules that provide a technical description of all the STM32L4 features including peripherals and development tools organized into specific sections: system, memory, security, analog, peripherals, watchdog and timers and ecosystem.


UP


July 2016 Power Management news from STMicroelectronics
  • Build smarter power supplies with green energy management

    The STEVAL-ISA177V1 evaluation board implements a wide-range converter in flyback non-isolated topology, delivering 0.85 A on a 5 V output based on ST’s new VIPer01 offline high-voltage converter from the VIPerPlus range that integrates an 800 V rugged power MOSFET with PWM current-mode control. The board’s main characteristics are its single layer, small size with minimal BOM, high efficiency and low standby consumption.

  • New high-voltage converter enables ultra-low consumption SMPS with a 5 V output voltage
    Integrating an 800 V avalanche-rugged logic-level MOSFET with PWM current-mode control and multiple protection circuits, the VIPer01 high-voltage converter enables designers to create a simple and ultra-low consumption SMPS in flyback, buck, or buck-boost configuration with a 5 V output. Its integrated high-voltage start-up and sense-FET, error amplifier, and oscillator with jitter minimizes the number of external components required to design a complete application.

  • Efficient switching regulator reduces cost and size of infotainment solutions

    The STEVAL-ISA188V1 evaluation board based on the A6986F synchronous step-down switching regulator can deliver up to 1.5 A and, with its 100% duty cycle ability to withstand cold crank events and wide input operating voltage range, represents the ideal choice for battery-powered automotive systems. Synchronous rectification helps achieve higher efficiency at full load as well as application compactness, while high-frequency switching (programmable up to 2 MHz) helps reduce the cost and size of power passive components while remaining outside the AM band. A low-noise mode can be selected to meet the requirements of infotainment applications with forced PWM mode under all load conditions.

  • High-performance PWM controller ideal for quick chargers and USB power delivery
    ST’s STCH02 is a current-mode controller designed for offline quasi-resonant ZVS flyback converters.
    The built-in 650 V HV start-up circuit with zero power consumption, combined with the fully integrated blocks for primary side constant current output regulation and the advanced power management make this IC the best choice to build high-efficiency and ultra-low standby consumption power supplies.

  • Evaluate our constant current controller for high-brightness LEDs

    The STCS1A constant current LED driver accurately controls the LED forward current in order to achieve good matching of light output.
    The STEVAL-ILL014V1 evaluation board demonstrates how the STCS1A is capable of controlling the LED current under several application conditions, while also providing useful features that make it suitable for different applications such as advertising signs, automotive interior and exterior lighting, and emergency vehicle warning lights.
UP


July 2016 Motor Control news from STMicroelectronics
  • Motor ControlEvaluate ST's complete solution with Wi-Fi for driving 3D printers

    The STEVAL-3DP001V1 is a complete solution for driving all 3D printers including Delta models requiring more complex computation.
    Ideal for both beginners and experienced users, this autonomous solution can be used with a software interface or with custom firmware.
    Designed to drive 3D printers providing several axes (6 motors), several extruders (1 to 3), and multi-zone heating beds (1 to 3), it features integrated Wi-Fi connectivity for use with a smart device.

  • New low-voltage motor drivers boost runtime of battery-powered IoT devices

    ST helps developers simplify the design, save space and extend the lifetime of battery-powered IoT devices with three new monolithic STSPIN motor drivers.
    Optimized for stepper (with a position accuracy of 256 microsteps per full step), DC brushed, and 3-phase BLDC motors, they operate from a supply voltage as low as 1.8 V and enable power savings thanks to the ultra-low, best-in-class standby current of less than 80 nA.
    Available in a 3 x 3 mm QFN package, they also benefit from comprehensive built-in protection features.

  • Eliminate bulky bypass relays and reduce steady-state losses

    The STEVAL-IHT008V1 evaluation board limits the inrush current charging a DC bus capacitor based on a soft-start procedure for the rectifier bridge controlled through a progressive phase-control during the startup phase.
    Compliant with the IEC 61000-3-3 standard, this front-end solution drastically reduces standby losses as the DC bus can be totally disconnected from the AC mains when it is not required, without needing an additional relay to open the circuit in standby.
  • VIDEO - Discover ST’s high-performance STSPIN motor driver ICs
    Excelling in integration, performance and efficiency, ST’s STSPIN motor driver ICs provide a scalable and flexible solution for all motor types thanks to their wide operating voltage (1.8 to 85 V), current (1.3 to 10 A) and temperature range (-40 to 150 °C). Available in multiple package options to meet a variety of design challenges, they feature extensive diagnostics and are fully-protected to reduce the number of external components, cost and design complexity.
  • VIDEO - Discover ST’s L6474 stepper motor driver expansion board in less than 3 minutes
    This video showcases ST's affordable and easy-to-use solution for driving stepper motors. Based on the L6474 motor driver, the X-NUCLEO-IHM01A1 STM32 Nucleo expansion board offers high levels of performance and robustness with its advanced current control and complete set of protection features.
    Compatible with the Arduino UNO R3 connector, the board supports the addition of other boards which can be stacked to drive up to 3 stepper motors using a single STM32 Nucleo board.
UP


July 2016 News and Updates from STMicroelectronics
  • Maximize battery life and lifespan with advanced charger management IC
    The STBC02 battery-charger management chip improves integration without compromising performance and power consumption.
    It combines a linear battery charger, a 150 mA LDO, two SPDT switches, a smart reset/watchdog, automatic power path management and a battery protection circuit.
    The STBC02 improves battery life and offers the perfect solution for wearable and IoT markets, reducing application cost, footprint and design time.

  • High-speed input current limiter cuts dissipation to enhance I/O module density
    Discover how you can enhance I/O module density by cutting dissipation (78 mW per input) and reducing the number of opto-transistors.
    Based on our CLT01-38SQ7 high-speed digital input current limiter, the STEVAL-IFP031V1 evaluation board implements an 8-line protected input termination and its 6.25 MHz SPI output serializes the input state transfer to the I/O module controller.
    In addition to being daisy-chain capable, each input section embeds a LED output for visual status.

  • The strongest and tiniest SLIC protection shaped to satisfy any telecom standard
    The LCP154DJF – a complete and compact SLIC protection solution – is intended to replace several components such as LCP1521S, PTCs and Trisil™ in compact applications.
    Its parameters comply with ITU-T K20/21/45 and GR1089-Core outdoor standards and its PowerFLAT™ (5 x 6 mm) package is tailored to comply with clearance requirements according to IEC 60950, optimize PCB area as well as simplify application certifications.

  • Increase performance when using tiny batteries with our new nanopower comparators
    New TS88x series of nanopower comparators, compatible with low supply voltages, enables longer operating times with smaller battery size.
    With a very low operating current, the TS88x series draws less than half the current of competing devices without trade-off on speed and can operate on a wide temperature range (-40 to +125 °C).
    Available in very small packages, they are perfect for use in portable applications.

  • New ultra-compact EMI filter with high-speed ESD protection for microSD cards
    The EMIF06-USD14F3 offers a highly compact EMI low-pass filtering solution for SD memory cards in a 2.37 mm² package, with pull-up resistors outside the chip, and an optimized pinout fitting any type and generation of memory card.
    Its embedded low capacitance protection keeps full compatibility with SDR104 mode (SD3.0) and clock frequencies up to 208 MHz.

  • New advanced 16 V process technology for CMOS voltage comparators
    The TSX3702 is part of a new generation of 16 V micropower CMOS voltage comparators that helps save energy and simplifies the analog system design for applications from automotive electronics to smart buildings and industrial controls. Based on an in-house advanced manufacturing process, it offers a high level of robustness with an increased ESD tolerance. Available in tiny packages, an automotive-grade version is also proposed.

  • VIDEO - Explore ST’s VIPerPlus portfolio of high-voltage converters
    Combining an 800 V avalanche-rugged MOSFET with a leading-edge PWM controller, ST’s VIPerPlus series of high-voltage converters is the perfect solution to make an SMPS with few components and a simple feedback.
    Thanks to the extremely low standby consumption (less than 4 mW at 265 VAC ) and high efficiency over a wide load range, they enable SMPS designs meeting the most demanding energy-saving regulations.

  • VIDEO - Learn about the advantages of ST’s 800 V MDmesh K5 MOSFETs
    ST’s range of 800 V MDmesh K5 MOSFETs features the industry’s lowest device on-state resistance (80 mΩ for an 800 V device in TO-247) while also reducing the gate charge for faster and more efficient switching.
    The devices also have high avalanche robustness making them ideal for highly reliable designs.
    With more than 45 devices in total (10 different RDS(on) values and 9 packages), they meet the high efficiency needs of a wide range of applications

UP


June 2016 Microcontroller news from STMicroelectronics

UP


June 2016 STM32 ODE news from STMicroelectronics
  • Build your modular sensor node and connect to Microsoft Azure in minutes

    The STM32 Open Development Environment provides developers with end-to-end solutions to explore and validate design concepts.
    Designed with modularity, completeness and ease of use in mind, this complete development suite wireless IoT sensor nodes makes harvested sensor data quickly available on Microsoft Azure.

    The solution comprises:

        STM32 Nucleo development board (NUCLEO-F401RE) is powered by a high-performance STM32F4 microcontroller and includes an integrated ST-LINK/V2-1 debugger and programmer.
        STM32 Nucleo motion MEMS and environmental sensor expansion board (X-NUCLEO-IKS01A1) features accelerometer, gyroscope and compass MEMS as well as pressure, temperature and humidity sensors.
        CE-, IC- and FCC-certified STM32 Nucleo Wi-Fi expansion board (X-NUCLEO-IDW01M1) is based on a low-power Wi-Fi b/g/n SoC with integrated power amplifier and SMD antenna to provide out-of-the-box connectivity.
        STM32 Nucleo dynamic NFC tag expansion board (X-NUCLEO-NFC01A1) uses an M24SR Dynamic tag based on the ISO/IEC 14443 NFC forum type 4 RF interface enabling NFC use cases such as simple Bluetooth pairing and other connection handovers.
        Pre-built software function pack (FP-CLD-AZURE1) implements application level functions allowing developers to prototype end-to-end IoT applications together with Microsoft Azure cloud services, to easily transmit real-time sensor data and receive commands.

    See this tutorial the SW is here.
UP


June 2016 Power Management news from STMicroelectronics
  • Low conduction losses and high system efficiency using our 500 W fully digital SMPS
    The STEVAL-ISA147V3 is a digital switch mode AC-DC converter consisting of two power stages:
    an input semi-bridgeless power factor corrector (SBPFC) controlled by an STM32F051K8, and a regulation stage implemented with an LLC half bridge with synchronous rectification (SR), controlled by an STM32F334C8 microcontroller. This 500 W AC-DC converter uses the so-called bridgeless PFC topology.

  • Inverting buck-boost LED driver board made easy
    The STEVAL-ILL079V1 product evaluation board is based on an LED6000 monolithic current source for high power LED driving. The solution fully supports topologies such as inverting buck-boost with digital dimming capabilities.
    A light load management feature, current limit threshold control and adjustable switching frequency make the solution ideal for optimized power applications.

  • Maximize ROI for USB-C: no-cost software and low-cost dev boards
    P-NUCLEO-USB001 ST's certified embedded software solution based on its industry-leading STM32F0 microcontroller makes USB-C adoption faster in end-products using the flexibility, adaptability, and versatile feature set of the STM32 ecosystem.
    At less than $50, the STM32 Nucleo pack (P-NUCLEO-USB001) development kit includes an USB-C and PD expansion board, two USB-C dual role ports (provider, consumer and DRP) and the Analog Frond End PHY to control the Configuration Channel (CC) lines.
  • For a clean, stable output voltage, try our new cost-effective high-PSRR LDOs
    The new LDK320 and LDL212 linear voltage regulators respectively provide 200 mA and 1.2 A of current.
    These cost-effective LDOs, able to work with supply voltages up to 18 V, offer an optimal combination of low dropout voltage, low quiescent current and remarkable dynamic performance.
    Thanks to the very high PSRR (more than 85 dB @ 120 Hz), they are recommended for applications requiring a clean and stable output voltage.
UP


June 2016 Automotive and Transportation news from STMicroelectronics
  • Discover new SPC57 S line: designed for stringent safety requirements at affordable cost
    The new 32-bit SPC570S automotive microcontrollers are designed for the most demanding and safety-critical applications targeting the highest ISO 26262 ASIL-D Safety Integrity Level, such as ABS and airbags.
    SPC570S microcontrollers operate at speeds up to 80 MHz and offer high performance processing with low power consumption. Developers will benefit from the complete Power Architecture® development ecosystem including drivers, operating systems and configuration code to assist with user implementations.

  • Evaluate SPC57 S Line MCUs at a budget price

    The SPC57S Discovery board for the SPC570S50E1 32-bit microcontroller offers full access to CPUs, I/O signals and peripherals such as CAN, UART, JTAG, K-Line, and LIN.
    An expansion connector makes it easy to plug in application and extension modules for rapid prototyping, while Arduino-compatible connectors allow the use of a wide choice of specialized shields.
    Developers benefit from the fully customizable SPC5Studio development environment with its intuitive user interface.

  • Reduce time-to-market using a professional development ecosystem

    A complete ecosystem is available for developing applications based on our SPC5 32-bit automotive MCUs in Eclipse IDE or AUTOSAR environments. These professional toolchains and IDEs provide a modular solution that reduces development time and ensures rapid prototyping. Developers will appreciate a full set of software libraries, evaluation boards, adapters and more.

  • Increase efficiency and battery autonomy in hybrid and electric vehicles
    ST's new AEC-Q101-qualified 650 V SiC 12- to 40-amp diodes feature a low VF at high temperature (175 °C) – at least 150 mV VF improvement versus 600 V silicon-based/ultrafast diodes – and a high-surge capability (IFSM ).
    Ideal for on-board battery chargers (OBCs) for hybrid and electric vehicles (HEVs, EVs), they prove superior efficiency as well as robustness.
    Housed in TO-220AC, DO-247 and TO-247 packages (with PPAP available upon request), their excellent thermal properties help to further improve overall vehicle reliability.

  • New 650 V SiC MOSFET to complete qualification to AEC-Q101 in early 2017
    Automotive June 2016 Currently sampling to lead customers, ST has extended its portfolio of SiC MOSFETs with the introduction of the 650 V, 22 mΩ typ (at 150 °C) SCTW100N65G2AG.
    The new device will complete the qualification to AEC-Q101 in early 2017 and features the industry’s highest junction-temperature rating of 200°C and shows a very small variation of the on-state resistance even at high temperatures for higher system efficiency.
    When used in the EV/HEV main inverter, it increases the efficiency by up to 3% compared with an equivalent IGBT solution, translating into longer battery life and a lighter power unit.

  • Try ST's newest automotive-grade high-frequency DC-DC regulator with up to 3 A

    The STEVAL-ISA160V1 evaluation board is based on the AST1S31HF PWM synchronous step-down regulator, whose very high switching frequency (2.3 MHz) allows miniaturizing the magnetic components (i.e. choke).
    Operating on a 2.8 to 4.0 V input voltage, it provides a regulated output voltage from as low as 0.8 V up to VIN , meaning that the duty cycle can reach 100% (when VOUT = VIN ) thus optimizing efficiency.
    A Power Good pin gives precise feedback to the MCU preventing the system from starting before the output voltage is stable. All evaluation board components are automotive grade.

  • Find best DC-DC solution with ST's automotive-grade regulator eval boards

    Designed for 5 V fixed output, the STEVAL-ISA189V1 evaluation board is based on our A6986F5V synchronous step-down switching regulator that can deliver up to 1.5 A and, with its 100% duty cycle ability to withstand cold crank events and wide input operating voltage range, represents the ideal choice for battery-powered automotive systems.
    Moreover, a low-noise mode improves the performance of infotainment applications. For a 3.3 V fixed output solution, have a look at our STEVAL-ISA188V1.

  • Shield onboard equipment with jump-start-compatible ESD protection
    The ESDLIN03-1BWY – housed in SOT323-3L – is a single-line ESD protection device designed to protect automotive equipment.
    AEC-Q101-qualified, it is suited for LIN or USB interfaces and much more as it combines a very-low capacitance (3.5 pF), a 300 MHz bandwidth and a 28.5 V breakdown voltage.
    Its excellent ESD and EOS capability makes it suitable for harsh environments since it exceeds ISO 10605 level 4, with 30 kV and reaches an IPP of 3.7 A (8/20 µs).

UP


June 2016 News and Updates from STMicroelectronics
  • Need Bluetooth Smart connectivity ? ST makes it simple

    Evaluate our BlueNRG-MS low-power Bluetooth® Smart IC using the STEVAL-IDB006V1 evaluation board. Compliant with Bluetooth® 4.1 enhancements, it further increases energy efficiency and supports master and slave roles concurrently. Featuring an onboard, low-power STM32L microcontroller, it can also be used for custom application development.

  • Increase your design’s efficiency with ST’s latest fast-diode MOSFETs
    With an RDS(on) of 0.350 Ω (max.), excellent performance in terms of trr (190 ns typ.), Qrr (1.111 µC typ.) and smooth soft switching behavior, ST's new 500 V MDmesh DM2 fast recovery diode MOSFETs, the STD12N50DM2 and STF12N50DM2, are sure to improve the efficiency of your design. Housed in DPAK and TO-220FP packages, they are ideal for home appliance and consumer applications (full bridge topology) and for lighting (LED drivers) applications based on LLC topology.

  • Increase immunity and reduce BOM with new 800 V AC switch
    Drive loads subjected to high AC lines spikes and transients with ST’s new logic level ACST310-8FP –  3 A, 800 V overvoltage-protected AC switch.
    Its high-voltage robustness and surge voltage capabilities prove its reliability in low-power appliance systems, and saves PCB space as any MOV protection or RC network can be removed.
    Available now in the 2kV UL1557-certified TO-220FPAB package, it allows any standard microcontroller to drive resistive or inductive load up to 250W.

  • High-temperature dynamic NFC tag adds capabilities for industrial applications
    Upgrade your applications working in harsh environments with our 64-Kbit, dual-interface M24SR64-Y dynamic NFC tag. Functioning at temperatures up to 105 °C (I²C mode) with 500k write cycle endurance, this NFC Forum Type 4 tag based on the ISO/IEC 14443 RF interface features a two-wire 1-MHz I²C serial interface, NDEF native support as well as a 128-bit password data protection mechanism.
    Developers will benefit from the X-NUCLEO-NFC01A1 reference design kit that includes a dynamic NFC tag expansion shield for STM32 Nucleo compatible with the Arduino UNO R3 connector layout.

  • Boost application performance with precision 16 V CMOS op amps
    Combining very high accuracy with a wide operating-voltage range and excellent robustness, ST’s TSX7 series of precision 16V op amps, with their rail-to-rail input and output functionality, can be used on a full input and output range without limitation. Their low input-bias current and the energy-efficient combination of low power consumption and gain bandwidth make the TSX7 series ideal for use in power-constrained sensor-signal-conditioning applications.

  • Enhance I/O module density and cut dissipation

    Improve I/O module density by cutting the dissipation (78 mW per input) and reducing the opto-transistor count using ST’s SCLT3-8BQ7, an 8-line protected digital input termination. In addition to embedding an adjustable digital filter and LED driver in each input section, its 2 MHz SPI peripheral output serializes the input state transfer to the I/O module controller. Developers can quickly evaluate our solution using the STEVAL-IFP030V1 evaluation board that also includes temperature and voltage alarms as well as daisy-chain capability.
UP


May 2016 Aereospace news from STMicroelectronics
  • Reduce the weight and cost of wires using high-speed serial comms in satellite sub-systems
    ST is expanding its rad-hard LVDS offer with the RHFLVDS217, an LVDS serializer, and the RHFLVDS218, an LVDS de-serializer, allowing a 1.575 Gbit/s data rate and a widened common-mode range spanning from –4 to +5 V with a 4.8 V supply for inter- and intra-board serial communication in satellites.
    ELDRS-free and immune to single-event latch-up (SEL), both devices feature best-in-class radiation immunity with 300 krad (Si). Engineering models are available in a hermetic ceramic Flat-48 package with industry standard pin-out and we target QML-V qualification soon.

  • Improve performance of satellite signal chains with our very low-noise DAC
    In satellite signal chain applications, three things are paramount: performance, consumption and radiation immunity.
    The RHRDAC1612, a high-resolution radiation-hardened DAC, addresses all three featuring superior linearity and a signal-to-noise ratio of 96 dB @ 3 kHz while consuming only 20 mW (at 12 kHz).
    All this while withstanding a total irradiating dose (TID) of 100 krad (MIL-STD-883 1019.7) and single-event latch-up (SEL) immunity up to 120 MeV.cm²/mg.
    Engineering models are available in a flat 24-pin hermetic ceramic package and we target QML-V qualification soon.

  • New single and quad rail-to-rail op amps with improved radiation immunity
    When it comes to handling narrowband signals - like the output from a temperature or position sensor in satellite telemetry applications – or buffering a DC reference, you need a precision, low-power op amp that can be used in multiples, simplifying both component selection and procurement.
    The new RHR61 (single) and RHR64 (quad) rad-hard CMOS op amps fit the job with a radiation immunity up to 100 krad TID, and SEL immunity up to 120 MeV.cm²/mg. Both are available as engineering models and we target QML-V qualification soon.

  • Widest selection of hermetic packages for our power bipolar transistors
    Industry-standard 2N5153 and 2N5154 complementary power bipolar transistors (80 V - 5 A, respectively PNP and NPN) are popular in many satellite designs.
    We are proud to offer the widest choice of hermetic package options with TO39, SMD.5 and TO-257 versions.
    Offered both in an immune to a 100 krad Low Dose Rate (LDR) version and non-radiation immune version, they are all included in the European Preferred Part List (EPPL) of the European Space Components Coordination (ESCC).
UP


 May 2016 IoT news from STMicroelectronics
  • Hassle-free development of wearable applications

    Often Internet of Things means wearable or battery-operated devices.
    The STEVAL-WESU1 is the new ST reference design which implements all you need to address the next wave of IoT devices.
    This small form-factor watch strap opens many possibilities for developing functions and applications using inertial and environmental sensors, Bluetooth low energy for data communication and low-battery management profiles.
    Developer resources include:
    • A fully customizable firmware package (STSW-WESU1) built around the STM32Cube™ framework that also offers several application examples.
    • The ST-WESU app available for iOS and Android that lets you access all STEVAL-WESU1 functions as well as enjoy a number of pre-installed demos including AHRS 3D-orientation, Activity Recognition and Carry Position.

  • Coin-cell battery-powered sensor board for sub-GHz wireless sensor networks

    A wireless sensor node in a Smart Home or Smart Things application - like thermostat and smoke detector systems or a smart remote control – needs to be as small as possible and frugal in its energy requirements so it can use a very small battery too. The STEVAL-IDI005V1 wireless sensor board provides motion and environmental sensing with certified sub-GHz connectivity – based on an SP1ML-868 module – in a tiny 30 x 30 mm form factor and running on a CR2032 coin-cell battery.
    Additional tools for exploring wireless sensor networks:
    • Pair it with the STEVAL-SP1ML868 USB dongle and build a peer-to-peer connection to retrieve data from the on-board sensors.
    • You can also use your Android smartphone or tablet to access all the capabilities of the STEVAL-IDI005V1 using our STSW-IDI005 Android app.
UP


 May 2016 news and updates from STMicroelectronics
  • Ensure Bluetooth Smart connectivity for your design

    Among a plethora of Bluetooth® 4.1 compliant devices, the BlueNRG-MS IC, exhibiting an unparalleled low current consumption, is ideal for applications that need to operate for months or even years while being powered from a small coin cell battery.
    Running a complete, upgradable BLE stack on an embedded Cortex®-M0 core, it is also connected through a proprietary SPI-based interface to a host MCU running the application.
    Supporting both master and slave roles, the BlueNRG-MS can operate as a central (managing up to 7 peripherals) or peripheral device without any change in the firmware.

  • High-speed current limiters cut power, cost, and board space in factory automation
    ST’s new digital-input current limiters – SCLT3-8BQ7 and CLT01-38SQ7 – provide industrial programmable logic controllers (PLCs) with robust protection against input-signal current spikes while reducing power consumption, board space, and component count, in the highly compact QFN-48L (7 x 7 mm) package.
    IEC 61000-4.2, -4.4, and IEC6100-4.5 compliant, they ensure better protection than other integrated or space-hungry solutions.
    Developers will also appreciate their temperature/voltage alarm options and energy-free LED output status indicators.

  • Achieve the best performance for the appropriate accuracy with our 36 V op amps
    Designed to deliver enhanced performance and ruggedness, ST's new generation of high-voltage op amps feature a wide supply-voltage range, stability in challenging environments, and tolerance to electrostatic discharges (ESD) up to 4 kV (HBM). Offering many possible combinations of power consumption and gain bandwidth, ST’s 36 V op amps, especially the TSB572 and TSB611, simplify the design of sensors for automotive and industrial applications. Developers will especially appreciate our interactive product selector apps for Android and iOS devices and an extensive set of SPICE and PSPICE simulation models.
  • Snubberless™ triac enhances the switching life of 3-phase AC controllers
    With its peak switching current up to 240 A and a 1200 V blocking voltage, the T2550-12 triac is dedicated to industrial 3-phase AC controllers.
    The T2550-12I version allows a compact design and offers 2500 V isolation with a 1.7 °C/W thermal resistance.
    Like its D²PAK and TO-220AB versions, its dynamic performance, 2500 V/μs immunity and 20 A/ms blocking turn-off, makes this device unique for industrial applications such as motor control or heating systems.

  • Evaluate the performance of ST’s new IO-Link transceiver device
    Fast demagnetization, reverse polarity, overload, overtemperature, ground and supply open wire protections are just some of the features of ST’s L6362A.
    You can now evaluate the full set of features of ST’s new L6362A transceiver for IO-Link and SIO mode communication with a dedicated evaluation board, the STEVAL-IFP017V3.
    The highly robust design of the L6362A allows the STEVAL-IFP017V3 to meet IEC 61000-4-4 (burst), IEC 61000-4-2 (ESD) and EN60947-5-2/IEC 61000-4-5 (surge) without additional external components.

  • VIDEO - Discover ST’s Smart Industry master and device solution for IO-Link and general-purpose transceivers
    Watch our e-presentation and see how ST’s L6360 and L6362A enable a master and device solution for IO-Link and general-purpose transceivers via a single 3-wire connection (PHY2) supporting COM1 (4.8 kbaud), COM2 (38.4 kbaud) and COM3 (230.4 kbaud) modes.
    Meeting all the remote service, standardization, functionality verification, diagnostics and monitoring requirements of modern sensors and actuators, they represent a compact, efficient and robust solution for the Industry 4.0.
UP


 May 2016 MEMS and SENSORS news from STMicroelectronics
  • Burning hot or freezing cold, this sensor still detects the slightest motion

    Discover our solution for industrial motion sensor applications requiring an extended temperature range and long lifespan.
    The STEVAL-MKI170V1 adapter board showcases our high-performance IIS328DQ 3-axis accelerometer that features ultra-low-power operational modes for advanced power-saving and smart sleep-to-wakeup functions.
    With dynamic, user-selectable full-scales of ±2g/±4g/±8g, the IIS328DQ can measure accelerations with output data rates from 0.5 Hz  to 1 kHz over a temperature range from -40 to +105 °C.

  • It's small. It's smart. It's our new ultra-low-power 3-axis accelerator

    The ultra-low-power LIS2DS12 MEMS digital output 14-bit 3-axes accelerometer offers embeds real and virtual sensors to provide pedometer and step functions, tilt, timestamp and significant motion detection.
    Able to generate interrupt signals by using hardware recognition of free-fall events, 6D orientation, tap and double-tap sensing, activity or inactivity, and wake-up events, its small size and low power consumption makes the LIS2DS12 a perfect solution for enhancing user experience with the latest mobile apps.

  • You can’t touch this! Or our 3-axis digital accelerometer will know

    The STEVAL-MKI168V1 adapter board helps you evaluate our IIS2DH 3-axis digital accelerometer.
    The board offers developers an efficient way to prototype and evaluate their MEMS-based motion sensor designs for anti-tampering, motion-activated or power-saving applications.
    Fully compatible with the STEVAL-MKI109V2 motherboard functioning as a bridge between the sensor and a PC, developers can use the downloadable graphical user interface (Unico GUI) or dedicated software routines for customized solutions.

  • The world's smallest pressure sensor can survive just about anything

    Delivered in a 2 x 2 x 0.75 mm package, the LPS22HB is not only the world’s smallest absolute pressure sensor, but also the only one offered in a full-molded package that provides the best thermal and mechanical robustness (high shock survivability > 20,000 g) while boosting the performance and offering the best trade-off between current consumption (down to 3µA) and noise (0.0075 hPa RMS).
    Able to function as a digital output barometer, the LPS22HB is guaranteed to operate over a temperature range extending from -40 to +85 °C.

  • New ultra-low-power 6-axis MEMS sensor module for “always-on” motion-sensing

    LSM6DSL is the new ultra-low-power gyroscope and accelerometer combo that thanks to its ultra-low-power consumption of 0.4 mA enables much longer “always-on” motion sensing, boosting the performance compared with the previous generation of iNEMO inertial modules. Featuring a 3D digital accelerometer and a 3D digital gyroscope, this system-in-package ensures an optimal motion experience for the consumer. Supporting main OS requirements, this module offers real, virtual and batch sensors with 4 Kbytes for dynamic data batching.

  • Live long and prosper - says our low-power 3-axis gyroscope

    Developers can take advantage of the continuity of supply for long-life applications with our low-power I3G4250D 3-axis digital output gyroscope.
    The STEVAL-MKI169V1 adapter board lets you evaluate its key features including a selectable full scale (±245/500/2000 dps), an embedded FIFO and programmable interrupt.
    Due to its high stability at zero-rate level and sensitivity over temperature and time, this flexible solution is especially suitable for industrial applications requiring high quality and long-term availability.

UP


UP
