Power PC
for automotive
The SPC56 family of 32-bit automotive microcontrollers is designed using Power Architecture™ and ST’s 90 nm embedded Flash technology. Developed within the framework of the STMicroelectronics/Freescale Joint Development Program (JDP), it combines a scalable range of e200 cores with innovative peripheral sets that are optimized for building efficient applications in engine management, chassis, safety, body control and instrument clusters.
The modular design concept and the ultimate performance of the technology together with the rigorous implementation of a zero-defect strategy will make it a reference platform for the next generation of automotive applications.
In general, documentation, application notes, software etc., refer to the website dedicated to STM56 which you can access by clicking:
Index:
Development tools, click here
Debugging and Emulation, click here
Code Generation, click here
Runtime Software, click here
Evaluation Board, click here
For more info contact your local SILICA office
Debugging and Emulation, click here
Code Generation, click here
Runtime Software, click here
Evaluation Board, click here
For more info contact your local SILICA office
Development
GreenHills MULTI
Green
Hills Software’s MULTI integrated development environment includes the
industry’s most powerful and proven tools for developing embedded
software with maximum reliability, maximum performance, and minimum
code size.
http://www.ghs.com/
http://www.ghs.com/
Wind River Compiler
Wind
River Compiler (formerly Diab) has a proven track record generating
robust, tight, compact, and fast-executing code while also delivering
the control and flexibility demanded by device software development.
Optimization technology builds on and extends the industry hardened
Diab compiler, providing both strong performance and reliability.
http://www.windriver.com/index.html
http://www.windriver.com/index.html
Cosmic Compiler
Cosmic's
C cross compilers are part of a complete and uniform compiler product
line. Cosmic's familiar and easy to use software interface is common
through all supported microcontrollers to simplify the learning curve
and the migration between targets.
http://www.cosmic-software.com/
http://www.cosmic-software.com/
CodeSourcery GNU Compiler
Sourcery
G++ is a complete software development environment based on the GNU
Toolchain. Sourcery G++ includes the GNU C and C++ compilers, the
Eclipse IDE, and much more.
http://www.codesourcery.com/
http://www.codesourcery.com/
ByteCraft eTPU C Compiler
High-performance
Code Development System for the eTPU. You can develop eTPU programming
completely in the C language. And eTPU_C can supply the information
your host compiler needs to initialize and control the eTPU.
http://www.bytecraft.com/
http://www.bytecraft.com/
ASH WARE eTPU Development Kit
Packages
the eTPU Stand-Alone Simulator with ETEC C Compiler. The eTPU
Stand-Alone Simulator provides a wide range of sophisticated simulation
and debugging capabilities such as an integrated graphical logic
analyzer, code coverage analysis, variable and watch windows, call
stack windows, trace, direct register modification, data verification,
and test verification.
http://www.ashware.com/
http://www.ashware.com/
Debugging and Emulation
Lauterbach TRACE32 Powerful debugger/emulator with integrated logic analyzer.
Universal
Trace Port Controller, 1 Gigabyte Trace Memory, 200 MHz Internal
Processing Speed, simple and complex triggers, 17 additional digital
channels. Includes LA-7945 (standard 17 channel probe). Requires Power
Debug II Ethernet.
Main features:
PLS Universal Access Debug 2 (UAD2) and Universal Debug Engine (UDE)Main features:
First choice emulator for automotive market
Enhanced functionalities for code tracing and analysis (memory, coverage, statistic and performance)
Integrated support for eTPU and RTOS debugging
Enhanced functionalities for code tracing and analysis (memory, coverage, statistic and performance)
Integrated support for eTPU and RTOS debugging
The Universal Debug Engine (UDE) is a flexible and fully integrated debug platform, supports JTAG and Nexus interfaces.
Features:
http://www.pls-mc.com/content/view/146/304/
Features:
eTPU debugging, USB, Firewire and Ethernet connection to host and CAN monitor port.
http://www.pls-mc.com/http://www.pls-mc.com/content/view/146/304/
Raisonance RLink and Raisonance Integrated Environment (RIDE)
RLink
has been designed to connect to the user application board via the USB
port allowing In-Circuit Programming and In-Circuit Debugging thanks to
the serial protocol included in the used microcontroller.
http://www.mcu-raisonance.com/spc56xx-support.html
http://www.mcu-raisonance.com/spc56xx-support.html
P&E WinIDE and Wiggler
The
USB-ML-PPCNEXUS debug interface is a high speed USB 2.0 peripheral for
SPC56xx devices via JTAG providing the ability to debug your target in
real time. Includes P&E's in-circuit debugger, flash programmer,
development environment with GCC C (non-VLE).
http://www.pemicro.com/index.cfm
http://www.pemicro.com/index.cfm
iSystem iC3000
The
iC3000 Active Emulator is the ultimate tool for high performance
microcontroller based embedded applications. Supports all famous On
Chip Emulation technologies like BDM, SDI, Once, JTAG and Nexus for On
Chip Debugging. For On Chip Trace ETM and Nexus solutions are available.
http://www.isystem.com/
http://www.isystem.com/
Code Generation
RAppID1X
The Mathworks Matlab
dSPACE
RAppID is a graphical interface for quick configuration of CPU core and peripherals of new SPC devices.
The GUI allows to easily define peripheral configuration and drive code generation.
RAppID not only generates C code for initializing the registers, but it also provides a system initialization function that brings the controller up in an orderly sequence.
RAppID is available in two versions:
The GUI allows to easily define peripheral configuration and drive code generation.
RAppID not only generates C code for initializing the registers, but it also provides a system initialization function that brings the controller up in an orderly sequence.
RAppID is available in two versions:
- Easy-to-use graphical user interface (GUI) for CPU and peripherals configuration
- Viewer for peripheral registers configuration
- Automatic check for consistency of the configuration
- Code generation support for GreenHills and Wind River compilers. Generated code is ANSI / MISRA compliant
- Enhanced automatic reporting functionalities on generated code
- Support for basic DMA configuration
- Support for full eTPU initialization, custom functions and code download.
- Full driver block set for Matlab/Simulink.
The Mathworks Matlab
State of the art modeling system
Product = Simulink
Optimized code generation through RAppID
Product = Real Time Workshop Embedded Coder
http://www.mathworks.com/dSPACE
Full system for code development covering from modeling to system validation.
Provides modules for PPC optimized code generation
http://www.dspaceinc.com/en/inc/start.cfm
Provides modules for PPC optimized code generation
Product = TargetLink
Full hardware and software support for calibrationhttp://www.dspaceinc.com/en/inc/start.cfm
Runtime Software
ETAS RTA-OSEK
Vector osCAN
RTA-OSEK provides an application design environment
that combines the smallest and fastest OSEK RTOS with an unique timing
analysis tool. OSEK/VDX v.2.2 certified. Overhead: 30 bytes RAM,
154bytes ROM, Category 2 interrupt latency: 131 CPU cycles.
http://www.etas.com/en/index.php?langS=true
http://www.etas.com/en/index.php?langS=true
Vector osCAN
osCAN
is a preemptive real-time multitasking operating system with optimized
characteristics for use on microcontrollers. 1-10 KB ROM.
Conformance classes: BCC1, BCC2, ECC1, ECC2, CCCA, CCCB.
http://www.vector.com/vi_index_en,,223.html
Vector MICROSAR OShttp://www.vector.com/vi_index_en,,223.html
MICROSAR
OS is a preemptive real-time multitasking operating system with
optimized properties for use on microcontrollers. Vector Informatik’s
many years of experience in developing operating systems and drivers
for microcontrollers has culminated in a small, robust operating system
core. AUTOSAR Scalability Classes 1 to 4. 1-20 KB ROM.
http://www.vector.com/vi_index_en,,223.html
http://www.vector.com/vi_index_en,,223.html
Green Hills μ-VelOSity
Elektrobit TresOS ECU
The µ-velOSity real-time microkernel is the smallest of Green Hills Software’s family of royalty-free operating systems.
Written in ANSI/ISO compliant C, µ-velOSity employs a rigorous coding style that includes MISRA-C safety subset enforcement.
http://www.ghs.com/products/micro_velosity.html
Written in ANSI/ISO compliant C, µ-velOSity employs a rigorous coding style that includes MISRA-C safety subset enforcement.
http://www.ghs.com/products/micro_velosity.html
Elektrobit TresOS ECU
Evaluation Board
SPC Evaluation board for SPC56xx devices. Allow to evaluate and develop the whole range of SPC devices.
Features:
Features:
Full modular design: motherboard, minimodule for each device, standardized connectors
Power supply: ST L9758
Standard communication transceivers and connectors
User’s buttons, jumpers and LED’s
Device mini-module connector
Standardized expansion connector
compatible with existing ST PT&S micros
Power supply: ST L9758
Standard communication transceivers and connectors
User’s buttons, jumpers and LED’s
Device mini-module connector
Standardized expansion connector
compatible with existing ST PT&S micros
