December 2015 MEMS News and Updates from STMicroelectronics
  • New ready-to-use libraries available for your sensor design
    ST releases two new Open.MEMS libraries to easily build applications using accelerometer measurements.
    The osxMotionAR and osxMotionCP libraries are adds-on for X-CUBE-MEMS1 and run on an STM32 MCU.
    The osxMotionAR detects in real-time user activity (stationary, walking, jogging, biking, and driving), while osxMotionCP provides real-time recognition of board position (on desk, in hand, near head, shirt or trousers pocket, and arm swing).
    Both algorithms use the lowest sampling frequency helping reduce the power consumption of the hosting platform.

  • "Medical-grade" accelerometer for new implantable applications
    Specifically designed for medical applications, including Class III FDA implantable devices such as cardiac pacemakers, implantable cardioverter defibrillators (ICDs), and neurostimulators, the MIS2DH ultra-low-power 3-axis accelerometer is capable of measuring a patient's activity and posture, which is crucial to dose the stimulus delivered by the implantable device and therefore to improve the effectiveness of the treatment and the patient's well-being.

  • No more blurry pictures with MEMS-based anti-shake
    The L2G2IS 2-axis MEMS gyroscope is specifically optimized for optical image stabilization in smartphones and digital still cameras.
    Benefiting from compact dimensions of just 2.3 x 2.3 x 0.7 mm, the L2G2IS can be easily integrated into the next generation of stabilized camera modules, where component size is critical. Key technical features of the new device include ±100 dps / ±200 dps full-scale range, 3- and 4-wire SPI interface, and integrated low- and high-pass filters with selectable bandwidth.

  • Gesture recognition code examples now available for time-of-flight sensor
    Thanks to its precise measurement of the distance of the target, the VL6180X time-of-flight sensor is able to differentiate a vertical tap gesture from a horizontal swipe, even at distances up to 40 cm.
    ST has developed gesture recognition code examples that you can experiment with using the VL6180X to enable innovative gesture recognition use cases.
    The X-CUBE-6180XA1 package includes the full API and code examples.
UP
December 2015 - Aerospace and Defence news from STMicroelectronics
  • Hi-rel NPN bipolar transistor now available with JANSR+ qualification
    The 2N3700HR, 80 V, 1 A NPN hi-rel transistor, qualified to JANSR more than 2 years ago, is now available with the JANSR+ low-dose-rate guarantee.
    In addition to the standard 100 krad high dose rate, it guarantees a wafer-by-wafer 100 krad low dose rate with an ELDRS characterization showing the drift of the key parameters is the same at low (0.1 rad/s) and very low (0.01 rad/s) dose rates.
    It therefore joins 2N2222A, 2N2907A, 2N5401 and 2N5551 hi-rel bipolar transistors in offering a best-in-class radiation guarantee within the JANS quality system.

  • Cost-effective rad-hard LVDS series is now QML-V qualified
    The new RHFLVDS315 quad LVDS driver and RHFLVDS325 quad LVDS receiver have just completed QML-V qualification and join the other four products in the series to offer 300 krad total ionization dose tolerance.
    They have a relaxed skew specification compared to the enhanced series allowing more competitive pricing when bit rates allow it.
    Engineering and flight models are available from stock.

  • 2nd generation rad-hard adjustable LDO regulator
    The new RHFL6000A 1.2 to 5.5 V adjustable output LDO regulator is guaranteed to 300 krads total dose and offers an enhanced SET capability, including no SET up to VIN=12 V with IOUT=300 mA and up to VIN=4 V with IOUT=1 A.
    Operating with an input voltage range from 2.5 to 12 V, it offers improved stability and accuracy, access to the control loop and an enhanced adjustable output current limit up to 2 A.
    It is supplied in a Flat-16P package with ground-connected lid.
    QML-V qualification is imminent.

  • New SerDes macro IP added to the 65 nm rad-hard ASIC platform
    C65SPACE-HSSL is a macro IP designed for the C65SPACE 65 nm rad-hard ASIC platform that is now being used by several European customers to develop their own ASICs.
    This rad-hard SerDes features four identical data slices, each composed of a separate data transmission and reception lane running independently to each other.
    Its embedded PLL provides a very stable 6.25 GHz internal bit clock which is synthesized from a lower frequency input reference clock.

  • RobuST defense grade products extended with candidate lists
    In addition to the already introduced active RobuST defense grade products published on www.st.com, ST has released lists of candidate devices by product type.
    On request, ST will evaluate the full introduction of candidate RobuST devices based on customer needs.
    Candidate devices are already in production as industrial or automotive grade products so links to the corresponding device datasheets are included in the lists.
